Diaphragm vacuum pump
GM-0.33b Oilless Aluminium Alloy Vacuum Pump
Product Introduction:
"Nanbei" GM-0.33B diaphragm vacuum pump has features of more advanced design, higher efficiency, longer operating life. It is an all new product engaging in the new and high technology. It is mainly used in medicinal products analysis, tenuously chemical engineering, biochemical pharmacy, food examination, investigating and solving criminal case, etc. It is an ideal product used with the high-accuracy chromatogram apparatus, rotary evaporators, and it is the essential equipment in the laboratory.
The body of "Nanbei" GM-0.33III diaphragm vacuum pump is made of aluminum alloy through die casting. It is antiseptic, sprayed, agile and beautiful. It has the features of higher antisepsis, wider working range. It can meet requirements of all kinds of working environments.
|
Product Name
|
Diaphragm pump
|
|
Pumping speed
|
20L/Min
|
|
Ultra pressure vacuum degree
|
≥0.08Mpa ;200mbar
|
|
Motor power
|
160W
|
|
Gas inlet diameter
|
φ6mm
|
|
Gas outlet
|
Silincer
|
|
Pump head
|
1
|
|
Dimension
|
215×120×235mm
|
|
Work environment temperature
|
7-40ºC
|
|
Pump body temperature
|
<55ºC
|
|
Weight
|
7.5Kg
|
|
Diaphragm
|
Imported
|
|
Valve plate
|
Imported rubber
|
|
Noise
|
<60BD
|
|
Power supply
|
220Vac,50Hz
|
